SKU | Thread Size | Anchor Length (mm.) | Drill Size (mm.) | Drill Hole Depth (mm.) | Pull-Out (kN) | Shear (kN) |
---|---|---|---|---|---|---|
FH-214 | #2 | 6.35 (1/4 in) | - | - | - | - |
FH-2516 | #2 | 7.93 (5/16 in) | - | - | - | - |
FH-238 | #2 | 9.52 (3/8 in) | - | - | - | - |
FH-414 | #4 | 6.35 (1/4 in) | - | - | - | - |
FH-4516 | #4 | 7.93 (5/16 in) | - | - | - | - |
FH-438 | #4 | 9.52 (3/8 in) | - | - | - | - |
FH-412 | #4 | 12.7 (1/2 in) | - | - | - | - |
FH-458 | #4 | 15.87 (5/8 in) | - | - | - | - |
FH-434 | #4 | 19.05 (3/4 in) | - | - | - | - |
FH-410 | #4 | 25.4 (1 in) | - | - | - | - |
FH-4114 | #4 | 31.75 (1 1/4 in) | - | - | - | - |
FH-4112 | #4 | 38.1 (1 1/2 in) | - | - | - | - |
FH-638 | #6 | 9.52 (3/8 in) | - | - | - | - |
FH-612 | #6 | 12.7 (1/2 in) | - | - | - | - |
FH-658 | #6 | 15.87 (5/8 in) | - | - | - | - |
FH-634 | #6 | 19.05 (3/4 in) | - | - | - | - |
FH-610 | #6 | 25.4 (1 in) | - | - | - | - |
FH-6114 | #6 | 31.75 (1 1/4 in) | - | - | - | - |
FH-6112 | #6 | 38.1 (1 1/2 in) | - | - | - | - |
FH-620 | #6 | 50.8 (2 in) | - | - | - | - |
FH-6212 | #6 | 63.5 (2 1/2 in) | - | - | - | - |
FH-630 | #6 | 76.2 (3 in) | - | - | - | - |
FH-738 | #7 | 9.52 (3/8 in) | - | - | - | - |
FH-712 | #7 | 12.7 (1/2 in) | - | - | - | - |
FH-758 | #7 | 15.87 (5/8 in) | - | - | - | - |
FH-734 | #7 | 19.05 (3/4 in) | - | - | - | - |
FH-710 | #7 | 25.4 (1 in) | - | - | - | - |
FH-7114 | #7 | 31.75 (1 1/4 in) | - | - | - | - |
FH-7112 | #7 | 38.1 (1 1/2 in) | - | - | - | - |
FH-720 | #7 | 50.8 (2 in) | - | - | - | - |
FH-7212 | #7 | 63.5 (2 1/2 in) | - | - | - | - |
FH-838 | #8 | 9.52 (3/8 in) | - | - | - | - |
FH-812 | #8 | 12.7 (1/2 in) | - | - | - | - |
FH-858 | #8 | 15.87 (5/8 in) | - | - | - | - |
FH-834 | #8 | 19.05 (3/4 in) | - | - | - | - |
FH-810 | #8 | 25.4 ( 1 in) | - | - | - | - |
FH-8114 | #8 | 31.75 (1 1/4 in) | - | - | - | - |
FH-8112 | #8 | 38.1 (1 1/2 in) | - | - | - | - |
FH-820 | #8 | 50.8 (2 in) | - | - | - | - |
FH-8212 | #8 | 63.5 (2 1/2 in) | - | - | - | - |
FH-830 | #8 | 76.2 (3 in) | - | - | - | - |
FH-1038 | #10 | 9.52 (3/8 in) | - | - | - | - |
FH-1012 | #10 | 12.7 (1/2 in) | - | - | - | - |
FH-1058 | #10 | 15.87 (5/8 in) | - | - | - | - |
FH-1034 | #10 | 19.05 (3/4 in) | - | - | - | - |
FH-1010 | #10 | 25.4 (1 in) | - | - | - | - |
FH-10114 | #10 | 31.75 (1 1/4 in) | - | - | - | - |
FH-10112 | #10 | 38.1 (1 1/2 in) | - | - | - | - |
FH-1020 | #10 | 50.8 (2 in) | - | - | - | - |
FH-10212 | #10 | 63.5 (2 1/2 in) | - | - | - | - |
FH-1030 | #10 | 76.2 (3 in) | - | - | - | - |
FH-1212 | #12 | 12.7 ( 1/2 in) | - | - | - | - |
FH-1258 | #12 | 15.87 (5/8 in) | - | - | - | - |
FH-1234 | #12 | 19.05 (3/4 in) | - | - | - | - |
FH-1210 | #12 | 25.4 (1 in) | - | - | - | - |
FH-12114 | #12 | 31.75 (1 1/4 in) | - | - | - | - |
FH-12112 | #12 | 38.1 (1 1/2 in) | - | - | - | - |
FH-1220 | #12 | 50.8 (2 in) | - | - | - | - |
FH-12212 | #12 | 63.5 (2 1/2 in) | - | - | - | - |
FH-1230 | #12 | 76.2 (3 in) | - | - | - | - |
FH-1412 | #14 | 12.7 (1/2 in) | - | - | - | - |
FH-1458 | #14 | 15.87 (5/8 in) | - | - | - | - |
FH-1434 | #14 | 19.05 (3/4 in) | - | - | - | - |
FH-1410 | #14 | 25.4 (1 in) | - | - | - | - |
FH-14114 | #14 | 31.75 (1 1/4 in) | - | - | - | - |
FH-14112 | #14 | 38.1 (1 1/2 in) | - | - | - | - |
FH-1420 | #14 | 50.8 (2 in) | - | - | - | - |
FH-14212 | #14 | 63.5 (2 1/2 in) | - | - | - | - |
FH-1430 | #14 | 76.2 (3 in) | - | - | - | - |
