PH
สกรูเกลียวเหล็ก รุ่น PH
กรุณาเลือกสินค้าเพื่อดูสเปค
| รหัสสินค้า | ขนาดเกลียว | ความยาว (mm.) | ขนาดรูคอนกรีต (mm.) | ความลึกรูคอนกรีต (mm.) | แรงดึง (kN) | แรงเฉือน (kN) |
|---|---|---|---|---|---|---|
| PH-214 | #2 | 6.35 (1/4 in) | - | - | - | - |
| PH-2516 | #2 | 7.93 (5/16 in) | - | - | - | - |
| PH-238 | #2 | 9.52 (3/8 in) | - | - | - | - |
| PH-414 | #4 | 6.35 (1/4 in) | - | - | - | - |
| PH-4516 | #4 | 7.93 (5/16 in) | - | - | - | - |
| PH-438 | #4 | 9.52 (3/8 in) | - | - | - | - |
| PH-412 | #4 | 12.7 (1/2 in) | - | - | - | - |
| PH-458 | #4 | 15.87 (5/8 in) | - | - | - | - |
| PH-434 | #4 | 19.05 (3/4 in) | - | - | - | - |
| PH-410 | #4 | 25.4 (1 in) | - | - | - | - |
| PH-4114 | #4 | 31.75 (1 1/4 in) | - | - | - | - |
| PH-4112 | #4 | 38.1 (1 1/2 in) | - | - | - | - |
| PH-638 | #6 | 9.52 (3/8 in) | - | - | - | - |
| PH-612 | #6 | 12.7 (1/2 in) | - | - | - | - |
| PH-658 | #6 | 15.87 (5/8 in) | - | - | - | - |
| PH-634 | #6 | 19.05 (3/4 in) | - | - | - | - |
| PH-610 | #6 | 25.4 (1 in) | - | - | - | - |
| PH-6114 | #6 | 31.75 (1 1/4 in) | - | - | - | - |
| PH-6112 | #6 | 38.1 (1 1/2 in) | - | - | - | - |
| PH-620 | #6 | 50.8 (2 in) | - | - | - | - |
| PH-6212 | #6 | 63.5 (2 1/2 in) | - | - | - | - |
| PH-630 | #6 | 76.2 (3 in) | - | - | - | - |
| PH-738 | #7 | 9.52 (3/8 in) | - | - | - | - |
| PH-712 | #7 | 12.7 (1/2 in) | - | - | - | - |
| PH-758 | #7 | 15.87 (5/8 in) | - | - | - | - |
| PH-734 | #7 | 19.05 (3/4 in) | - | - | - | - |
| PH-710 | #7 | 25.4 (1 in) | - | - | - | - |
| PH-7114 | #7 | 31.75 (1 1/4 in) | - | - | - | - |
| PH-7112 | #7 | 38.1 (1 1/2 in) | - | - | - | - |
| PH-720 | #7 | 50.8 (2 in) | - | - | - | - |
| PH-7212 | #7 | 63.5 (2 1/2 in) | - | - | - | - |
| PH-838 | #8 | 9.52 (3/8 in) | - | - | - | - |
| PH-812 | #8 | 12.7 (1/2 in) | - | - | - | - |
| PH-858 | #8 | 15.87 (5/8 in) | - | - | - | - |
| PH-834 | #8 | 19.05 (3/4 in) | - | - | - | - |
| PH-810 | #8 | 25.4 (1 in) | - | - | - | - |
| PH-8114 | #8 | 31.75 (1 1/4 in) | - | - | - | - |
| PH-8112 | #8 | 38.1 (1 1/2 in) | - | - | - | - |
| PH-820 | #8 | 50.8 (2 in) | - | - | - | - |
| PH-8212 | #8 | 63.5 (2 1/2 in) | - | - | - | - |
| PH-830 | #8 | 76.2 (3 in) | - | - | - | - |
| PH-1038 | #10 | 9.52 (3/8 in) | - | - | - | - |
| PH-1012 | #10 | 12.7 (1/2 in) | - | - | - | - |
| PH-1058 | #10 | 15.87 (5/8 in) | - | - | - | - |
| PH-1034 | #10 | 19.05 (3/4 in) | - | - | - | - |
| PH-1010 | #10 | 25.4 (1 in) | - | - | - | - |
| PH-10114 | #10 | 31.75 (1 1/4 in) | - | - | - | - |
| PH-10112 | #10 | 38.1 (1 1/2 in) | - | - | - | - |
| PH-1020 | #10 | 50.8 (2 in) | - | - | - | - |
| PH-10212 | #10 | 63.5 (2 1/2 in) | - | - | - | - |
| PH-1030 | #10 | 76.2 (3 in) | - | - | - | - |
| PH-1212 | #12 | 12.7 (1/2 in) | - | - | - | - |
| PH-1258 | #12 | 15.87 (5/8 in) | - | - | - | - |
| PH-1234 | #12 | 19.05 (3/4 in) | - | - | - | - |
| PH-1210 | #12 | 25.4 (1 in) | - | - | - | - |
| PH-12114 | #12 | 31.75 (1 1/4 in) | - | - | - | - |
| PH-12112 | #12 | 38.1 (1 1/2 in) | - | - | - | - |
| PH-1220 | #12 | 50.8 (2 in) | - | - | - | - |
| PH-12212 | #12 | 63.5 (2 1/2 in) | - | - | - | - |
| PH-1230 | #12 | 76.2 (3 in) | - | - | - | - |
| PH-1412 | #14 | 12.7 (1/2 in) | - | - | - | - |
| PH-1458 | #14 | 15.87 (5/8 in) | - | - | - | - |
| PH-1434 | #14 | 19.05 (3/4 in) | - | - | - | - |
| PH-1410 | #14 | 25.4 (1 in) | - | - | - | - |
| PH-14114 | #14 | 31.75 (1 1/4 in) | - | - | - | - |
| PH-14112 | #14 | 38.1 (1 1/2 in) | - | - | - | - |
| PH-1420 | #14 | 50.8 (2 in) | - | - | - | - |
| PH-14212 | #14 | 63.5 (2 1/2 in) | - | - | - | - |
| PH-1430 | #14 | 76.2 (3 in) | - | - | - | - |
